WingtraOne



Mapping drone for high-accuracy aerial surveys.

The WingtraOne VTOL mapping drone is capable of performing fast aerial surveys across wide or hard-to-reach areas and producing reliable maps with unparalleled resolution and accuracy.

VERTICAL TAKE-OFF AND LANDING (VTOL)

Take off and land like a helicopter, fly like an airplane

Vertical take-off and landing (VTOL) capability allows the WingtraOne mapping drone to ascend and move like a helicopter. For the drone mapping, it transitions into a forward cruise flight, matching the endurance and speed of fixed-wing survey drones. In order to land, the WingtraOne switches back to hover flight and descends vertically.

MID AND LARGE-SCALE AERIAL DRONE SURVEY

Mapping large areas has never been this easy

Vertical take-off and landing (VTOL) capability allows the WingtraOne mapping drone to ascend and move like a helicopter. For the drone mapping, it transitions into a forward cruise flight, matching the endurance and speed of fixed-wing survey drones. In order to land, the WingtraOne switches back to hover flight and descends vertically.



Thanks to its high-resolution cameras, WingtraOne can fly at a high altitude above the ground and still map large areas with low GSD. Together with its fixed-wing design and flight time, WingtraOne makes it possible to complete large projects that were previously only possible with manned aircraft. Vast forests, mountain ranges and even the world’s largest mines can now be mapped in just a few hours.



Maximum flight time and coverage varies depending on payloads and environmental factors.

Map up to

400 ha.



in a one-hour flight

Up to

59 min



flight time

BEST DRONE SURVEY EQUIPMENT

Best-in-class equipment for the most accurate results

WingtraOne PPK sets the new benchmark for drone survey equipment. Thanks to its design, a professional drone PPK GNSS L1/L2 receiver and high-quality mapping cameras, like the 42 MP full-frame Sony RX1RII, it is now possible to reach down to 1 cm (0.4 in) absolute accuracy with an aerial survey drone.

The economical WingtraOne QX1 PPK combination guarantees absolute accuracy down to 3 cm (1.2 in) with the largest available

coverage at 120 m (400 ft).

Up to

42 MP



full-frame camera

L1 / L2

PPK



receiver for higher accuracy

Down to

0.7cm / px GSD



(0.3 in/px) GSD

Down to

1 cm



(0.4 in) absolute accuracy

Get a Quote
